SXR05-16 16 CHANNEL AHR

IP video input:

32-ch

Two-way audio input:

1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

Incoming bandwidth:

256Mbps

Outgoing bandwidth:

160Mbps

Remote connection:

128

Video/Audio Output

HDMI Output:

1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz,

1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Recording Resolution:

8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Audio Output:

1-ch, RCA (Linear, 1kΩ)

Synchronous Playback:

16-ch

VGA Output:

1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Decoding

Live view / Playback:

8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Capability:

8-ch@1080P

Hard Disk

SATA:

2 SATA interfaces for 2HDDs

Capacity:

Up to 4TB capacity for each HDD

External Interface

Network Interface:

RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces

Serial Interface:

RS-485;

USB Interface:

 2 × USB 2.0

Alarm In:

16-ch

Alarm Out:

4-ch

General

Power Supply:

DV12V2A

Consumption

≤20 W

Working Temperature:

-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)

Working Humidity:

10 % ~ 90 %

Dimensions:

323 × 240 × 51 mm

Weight(without HDD):

≤ 3 Kg
