Explosion Proof Camera PTZ

  • SS12 Explosion Proof PTZ Infrared Camera
  • SS12 Explosion Proof PTZ Infrared Camera
  • SS12 Explosion Proof PTZ Infrared Camera
  • SS12 Explosion Proof PTZ Infrared Camera
  • SS12 Explosion Proof PTZ Infrared Camera
SS12 Explosion Proof PTZ Infrared Camera SS12 Explosion Proof PTZ Infrared Camera SS12 Explosion Proof PTZ Infrared Camera SS12 Explosion Proof PTZ Infrared Camera SS12 Explosion Proof PTZ Infrared Camera

SS12 Explosion Proof PTZ Infrared Camera

  • support analog video output
  • Support Pelco-D, Pelco-P
  • 700TVL (color), 720TVL (B&W)
  • 530*280*396mm
  • Product description: SS12 Explosion Proof PTZ Infrared Camera
  • INQUIRY

SS12 Explosion Proof PTZ Infrared Camera



Certificate

Certificate Mark

ExdⅡC T6 GB/DIP A20 TA, T6

Certificate No

CNEx14.0068

Standards

Q/320412

Mechanical

Housing

Stainless steel 304 or 316L

IP

IP68

Cable thread hole

1pcs G3/4 or NPT3/4

Wiper

yes

Electrical

Voltage

AC85VAC265V or DC24Vor AC24V

Power

50W  /70W (with thermostat)

Ambient

Ambient temperature

-25 to +60℃

Air pressure

80Kpa to 106Kpa

Relative Humidity

≦95% (no condensation)

Lights

Light distance

100m

Light control

Support

Communication

Communication

support analog video output

485 Communication

Support Pelco-D, Pelco-P

Communicate Rate

2400 to 19200bps

Pan & Tilt

Horizontal

360°

Horizontal speed

0.1-45°/s

Vertical

 -90 to +90°

Cruise Scan

Support

Keep watch

Support

Preset

64/128/255/300

Resume function

Support

Auto Cruise

Support

Auto Pattern

Support

Auto Scan

Support

Camera

Image Sensor

1/3" interline-transfer CCD

Effective pixel

PAL 976*582  NTSC 976*494

Min. Illumination

Color 0.04Lux   B/W: 0.004Lux

Shutter Time

1/50(1/60) sec~ 1/10,000 sec

Day&Night

Auto ICR

Horizontal resolution

700TVL (color), 720TVL (B&W)

S/N ratio

50dBAGC off

Lens

Focal Length

 4-92mm, 23X/or 36X optical

Aperture Range

F1.5-F3.6

Angle of View

49-2.2 degree(Wide-Tele)

Min. Working Distance

10mm-1500mm(Wide-Tele)

Zoom Speed

Approx. 3s(Optical, Wide-Tele)

Control

Camera address

on/off 0-254

Focus Mode

Auto/Manual/One touch

Gain

off/ lower/ higher

Slow shutter

X256 MAX

White Balance

Auto white balance 1/auto white balance 2/Manual/auto

Private

Off/ Mode 1/ Mode 2

Video

3D DNR, mirror, brightness,  Contrast, Sharpness adjustable

Digital zoom

 X16

Zoom display

on/off

ZCF control mode

 mode 1, mode 2

RS485

protocol, baud rate, address

Preset

254

General

Cable

integrated cable

Size

530*280*396mm

Weight

27kg

Mounted

wall, pole

Wall bracket

SP20

Dimension
