Optional Camera

HIKVISION DS-2CD2820FWD BULLET 2.0MP NETWORK

2.0MP
1920 × 1080
NETWORK
HIKVISION
Product description: HIKVISION DS-2CD2820FWD BULLET 2.0MP NETWORK
INQUIRY

DS-2CD2820FWD
Key Features
l Up to 2 megapixel (1920 × 1080) resolution, real-time output
l Standard video compression with high compression ratio, ROI (region of interest) encoding
l Progressive scan CMOS, capture motion video without incised margin
l Support dual stream, and the sub-stream for mobile surveillance
l Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB
l IR cut filter with auto switch
l PoE (Power over Ethernet)
l 120dB wide dynamic range
l 3D DNR & DWDR
l Backlight compensation, electronic shutter for different surveillance environments
l Other functions: reset, heartbeat, mirror, PTZ control, IP address filtering, etc
l Support intrusion detection and line crossing detection
l Support VCA, which is compatible with NVR for the second time of video searching and analysing
Specification
Parameter	2 Megapixel CMOS Network Box Camera
Camera
Image Sensor	1/2.8" Progressive Scan CMOS
Min. Illumination	Color:0.01 Lux ,B/W 0.001 Lux, [F1.2,AGC ON]
Shutter Speed	1/3 s to 1/100,000 s
Lens Mount	C/CS
Day &Night	IR cut filter with auto switch
Digital Noise Reduction	3D DNR
Wide Dynamic Range	120dB
Compression Standard
Video Compression	H.264/ MJPEG
Video Bit Rate	32 Kbps – 8 Mbps
Dual Stream	Yes
Audio Compression	G.711/G.722.1/G.726/MP2L2
Audio Bit Rate	64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) /
	32-128Kbps(MP2L2)
Max. Resolution	1920 × 1080
Frame Rate	50Hz: 25fps(1920 × 1080) 25fps (1280 × 960), 25fps (1280 × 720)
	60Hz: 30fps(1920 × 1080) 30fps (1280 × 960), 30fps (1280 × 720)
Image Settings	Rotate mode, Saturation, Brightness, Contrast adjustable by client
	software or web browser
Backlight compensation	Yes, zone optional
ROI	Support
Network
Network Storage	NAS (Support NFS,SMB/CIFS)
Alarm Trigger	Intrusion detection, Line crossing detection, Motion detection, Dynamic
	analysis, Tampering alarm, Network disconnect , IP address conflict
Protocols	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
	PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPV4,IPv6,Bonjour
General	One-key reset, Flash-prevention, dual stream, heartbeat, mirror,
	password protection, privacy mask, watermark, IP address filtering,
	Anonymous access
Standard	ONVIF, PSIA, CGI, ISAPI
Interface
Communication	1 RJ45 10M/100M Ethernet interface, 1RS485 interface
Interface
Alarm Input	1
Alarm Output	1
Audio Input	1-ch 3.5 mm audio interface, Mic in/Line in
Audio Output	1-ch 3.5 mm audio interface
Video Output	1Vp-p Composite Output(75Ω/BNC)
General
Operating Conditions	-30 °C – 60 °C (-22 °F – 140 °F)
	Humidity 95% or less (non-condensing)
Power Supply	12 V DC ± 10% , PoE (802.3af)
Power Consumption	Max. 9 W
Dimensions	68×56×144 mm (2.58” × 2.13” × 5.47”)
Weight	700g (1.54 lbs)
